Can-Am Canyon

The all-new, adventure-ready 3-wheel vehicles are now available! Meet the Can-Am Canyon, Canyon XT and Canyon Redrock models, built for any kind of roads.

On the high-end 3-wheel Canyon Redrock you’re surrounded by comfort, with 2-up plush seating, SmartShox semi-active suspension, advanced tech like back-up camera, and unique colors and trims to make your ride your own.

Designed for easy access
Feel confident on the new Canyon!
The Can-Am Canyon makes adventure riding easy with remarkable stability and versatility on any terrain, from highways to dirt roads. Perfectly balanced, it inspires confidence for riders of all skill levels, making technical (and fun) trips accessible to everyone!

Ready for any adventure
Conquer every road on the Canyon
The Canyon 3-wheel is made to tackle all roads, with its rugged design and purpose-built features such as high ground clearance, extended suspension travel, XPS adventure tires, and adventure-style seating position. The new Canyon is the ideal thrill ride for long and short journeys.

Don’t leave the good stuff behind
FULLY CUSTOMIZABLE STORAGE FOR ADVENTURE
Designed to take you on short hops and extended journeys, on any kind of roads. Using the tool-less, customizable LinQ system for storage, you can take all your essentials and much more as you travel, switching out accessories in seconds. The Canyon promises perfect balance and peace of mind on every adventure.

ENGINE
Type: Rotax 1330 ACE in-line 3 cylinders, liquid-cooled with electronic fuel injection and electronic throttle control
Bore & Stroke: 84 x 80 mm (3.31 x 3.14 in.)
Power: 115 hp (85.8 kW) @ 7250 RPM
Torque: 96 lb-ft. (130.1 Nm) @ 5000 RPM
CO2 Emissions: 167 g/km
Fuel Consumption: 7.2 l/100 km (32.7 mpg)

TRANSMISSION
Type: Semi-automatic with reverse function
Gears: 6-speed

CHASSIS
Front suspension: Double A-arms with anti-roll bar
Front shock type/travel: SACHS Big-Bore shocks / 260 mm (10.2 in.)
Rear suspension: Swing Arm
Rear shock type/travel: KYB Smart-Shox with self-leveling air preload adjustment / 9.2 po (235 mm)
Electronic Brake Distribution System: Foot-operated, hydraulic 3-wheel brake
Front Brakes: 270 mm discs with Brembo, 4-piston fixed caliper
Rear Brake: 270 mm disc, 1-piston floating caliper with integrated parking brake
Parking Brake: Electrically actuated
Front Tires: XPS Adventure - 155/65 R16 MC 72H
Rear Tire: XPS Adventure - 225/50/R15 MC 84H
Aluminum Front Rims: 12-spoke, Carbon Black / Alloy Orange, 406 x 127 mm (16 x 5 in.)
Aluminum Rear Rim: 6-spoke, 381 mm x 178 mm (15 x 7 in.)

CAPACITY
Rider capacity: 2
Maximum Vehicle Load: 280 kg (617 lb)
Storage Capacity: 120,6 L (31.86 gal)
Fuel Capacity: 27 L (7.1 gal)
Fuel Type: Premium unleaded

DIMENSIONS
L x W x H 2547 x 1581 x 1500 mm (100.3 x 62.2 x 59 in.)
Wheelbase 1718 mm (67.6 in.)
Seat height 843 mm (33.2 in.)
Ground clearance 169 mm (6.65 in.)
Curb weight 470 kg (1036 lbs)

INSTRUMENTATION
Type 10.25 in. touchscreen display with BRP Connect and Apple CarPlay
Main functions: Speedometer, tachometer, odometer, trip and hour meters, fuel consumption avg, gear position, Drive mode, Custom Mode, temperature, engine lights, electronic fuel gauge, clock and more.
Audio system: USB, Bluetooth

SAFETY & SECURITY
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS Dynamic Power Steering
Anti-theft system Digitally Encoded Security System (D.E.S.S.)
HHC Hill Hold Control

COVERAGE
Factory warranty 2-year BRP Limited Warranty
Extended service terms: 2-year roadside assistance provided by Allianz Assistance, world leader in Automotive and Travel assistance, on behalf of BRP

FEATURES
LED headlights
Metal radiator grille
Adjustable windshield
Phone compartment with USB port
Hand guards
Integrated LinQ attachment points
Cruise control
Enduro anti-slip pegs
Adjustable Drive modes
Belt protector
143 mm (5.6 in) Handlebar riser
Custom drive modes
Aluminium top & side case
Driver and passenger heated grips
Passenger backrest
Self-leveling rear air suspension
Comfort pegs
Front Skid plate
Comfort seat
Back-up camera
Smart-Shox Semi-active supension
